PRODUCTS
Multifunctional powder coating
(KPL98 series) fluorocarbon powder coating Made of 70% PVDF resin and inorganic ceramic pigment made of building powder coating Typical use: senior architectural coating metal curtain wall, profile sound barrier Features: excellent corrosion resistance,Excellent weather resistance,Good chemical resistance,The coating is thin and the flatness is good Warranty: Kaopu Le Company guarantee, the use of "Kaopu Le" approved coating equipment, according to the product Description and technical description Under normal conditions, proper construction, fluorocarbon powder The column coating can form a smooth and matte finish that meets or exceeds the AAMA260 5 standard. Standard Package: 20Kg carton Specific gravity: 1.2-1.7g / cm³ (depending on the different weight of color) Theoretical coverage: 1Kg powder can be 40μm average thickness coating 14.7M ² (due to paint and construction conditions vary) Appearance: Color: Flat Matte: about 30-40% Sand pattern: sand, fine sand Monochrome and Metal Effects * * ISO2813 / 60 ° angle * Metallic effect gloss does not assess Custom Fluorocarbon Series Powder: Fluorocarbon powder is complete, covering all colors of RAL color card. It also provides matte finish with similar gloss and color. Dry storage stability: 6 months (≤ 25 ℃ environment) Substrate and its pretreatment: Aluminum should be treated in accordance with ASTM D 1730 TYPE B Method 5 (treated with amorphous chromium phosphate) and 7 amorphous chromate) The weight of the conversion film should not be less than 431 mg / M² (40 mg / ft²) Construction method: corona electrostatic spraying Please note: Other auxiliary products, such as sealants, glass glue, polished wax, drilling, and cutting lubricants, will contact the coating surface; before use should be confirmed that the PH value is neutral, and does not contain damage to the coating Ingredients. It is strongly recommended that the construction unit carry out the relevant tests before painting. Test results: the test Puluo Fluorocarbon powder series of matte finish coating test. The substrate was 0.7 mm thick by chromate-treated aluminum plates and pretreated according to ASTM D1730TypeB Method 5 or 7. The curing conditions follow the curing curve.
Product Description: This series of products is epoxy polyester resin mixture, curing agent and pigment based on the preparation of a thermosetting powder coating. Its lightfastness and heat resistance are better than epoxy powder coatings. The Powder performance: the proportion of 1.3-1.7 g / cubic centimeter (due to different colors and recipes) Particle size determination: Average particle size D50: 20-25 microns Packaging 20KG carton packaging, lined with plastic bags Storage period of 8 months (25 ℃ constant temperature) Application tools Corona electrostatic spraying / friction Sassafras live spray Coating thickness 40-50 microns (depending on the spray material) Coated area of 14-16 square meters per kilogram (theoretical area) Curing conditions 160 ° C / 25 minutes and 180 ° C / 15 minutes or 200 ° C / 10 minutes (material surface temperature) Appearance of the coating gloss (60 degrees angle) 80-90% high light; 40-70% half light; 15-30% matte; ≤ 15% matte. Smooth or wrinkle effect and special effects machine Mechanical performance test tinplate degreasing phosphating model, film thickness 40-60 microns, the national standard experimental conditions to complete. Pencil hardness GB / T6739-86 2H-4H Adhesion GB / T9286-88 Level 0 Bending experiment GB / T11185-88 0 Cup test (Eriksson value) GB / T9753-88 6-8 mm Impact Experiment GB / T1732-93 Positive / Reverse 1 KG / 50cm Corrosion resistance All test panels are degreased with phosphating method, the film thickness of 90-100 microns in the national standard experimental conditions to complete. Salt spray test ASTMB117 / GB1771-91 1000 hours after no effect, and cross-section corrosion less than 2 mm. Hot and humid experiment BS.3900PART F2 1793 3000 hours; GB1740 / 799 (89) 1000 hours after no effect, slightly lost light. Applications Office furniture / household appliances / automotive interior parts / machinery / toys Note: This series of products can not be used for outdoor use, or will make the film discoloration, fading, powder and other issues. IMPORTANT: Our oral and written presentations regarding the use of the product are derived from our experience and are based on current technical standards. Purpose To provide assistance to customers and users, they do not assume any obligations or purchase agreements Assume any responsibility for the user to verify the suitability of the product before using the product.
Industrial polyurethane powder coating
Product Description: This series of products is saturated hydroxyl poly resin and special crosslinking agent, weathering organic and inorganic pigments based on the preparation of a thermosetting polyurethane powder coating. With excellent leveling, excellent light resistance and excellent weather resistance and better pencil hardness. Powder performance: Specific gravity 1.3-1.7 g / cm (depending on color and formula) Particle size measurement Average particle size D50: 20-25 microns Packaging 20KG carton packaging, lined with plastic bags Storage period of 8 months (25 ℃ constant temperature) Application tools Corona electrostatic spraying / friction Sassafras live spray Coating thickness 30-40 microns (depending on the spray material) Coated area of 14-16 square meters per kilogram (theoretical area) Curing conditions 180 ° C / 15 minutes or 200 ° C / 10 minutes (material surface temperature) Coating appearance Gloss (60 ° angle) 80-90% high light; 40-70% half light; 15-35% matte; ≤ 15% matte. Smooth or wrinkle effects and special effects Mechanical behavior Experimental tinplate degreasing phosphating model, film thickness 60-80 microns, the national standard experimental conditions to complete. Pencil hardness GB / T6739-86 2H-4H Adhesion GB / T9286-88 Level 0 Bending experiment GB / T11185-88 0 Cup test (Eriksson value) GB / T9753-88 8 mm Impact Experiment GB / T1732-93 Positive / Reverse 1 KG / 50cm Corrosion resistance All experimental samples are degreasing phosphating method, the film thickness of 90-100 microns in the national standard experimental conditions to complete. Salt spray test ASTMB117 / GB1771-91 2000 hours after no effect, and cross-section corrosion less than 2 mm. Hot and humid experiment BS.3900PART F2 1793 3000 hours; GB1740 / 799 (89) 1000 hours after no effect, slightly lost light. Applications Indoor and outdoor furniture / household appliances / automotive interior parts / machinery / toys IMPORTANT: Our oral and written presentations regarding the use of the product are derived from our experience and are based on current technical standards. Purpose To provide assistance to customers and users, they do not assume any obligations or purchase agreements Assume any responsibility for the user to verify the suitability of the product before using the product.
Weathering properties of resin, inorganic pigments, organic high weathering pigments made of building powder coating Typical use: Advanced architectural painting Metal curtain wall, profile features: Powder particle size; 18-23 microns Excellent weather resistance The coating is thin and the flatness is good Good leveling Warranty: Kopler guarantees. The use of "Kaobu Le" weather series approved coating equipment, in accordance with the product and technical specifications under normal conditions, the correct construction, weathering series can form a smooth light / semi-light and matte coating, in line with or even exceed the provisions of AAMA2603-2002 The indicators. Standard Package: 20Kg carton Specific gravity: 1.4-1.7g / cm³ (depending on the different weight of color) Theoretical coverage: 1Kg powder can be 40μm average thickness coating 13.7M ² (due to differences in paint and construction conditions vary) Appearance | Color: Flattened: about 80-95% Flat half-light: about 40-70% Flat matte: about 15-30% flat matt: ≤ 15% Texture: bright Metal effect: stable performance * ISO2813 / 60 ° angle Customized ultra weather series powder: "Kaopu Le" series of ultra-weather powder coating color Complete, covering all colors of the RAL color card. It can also provide other colors that are close to a flat or matte finish. After long-term exposure to ultraviolet light, the gloss and color of the coating have a certain degree of decline is the general situation. Dry storage stability: 8 months (≤ 25 ℃ environment) Substrate and its pretreatment: Aluminum should be in accordance with ASTM D 1730 TYPE B standard, using multi-grade chromate pretreatment process DIN50 939 standard method 5 or 7. Or other approved pretreatment methods. Construction methods: static or friction gun spray, manual or automatic can be. Metal flash powder can only be used electrostatic spray gun. Excellent weather resistance: 27 ° in the north latitude of Florida 45 ° tilt angle exposed RAL-8018 *
CASE CENTER
ABOUT US
Jiangsu Kaopule New Material Co., Ltd.
founded in 2004, is a high-tech enterprise with proprietary intellectual property rights. Restructured from Changzhou Xingang Gaoli Chemical Co., Ltd. in 2010, our company has an “Honest and Trustworthy, Diligent and Dedicated, Innovative and Pragmatic, Harmonious and Sharing” team, is mainly engaged in R&D, production and relevant service of eco-friendly and functional coatings, and provides professional complete coating programs for customers.
OHSAS-18001
ISO 9001
ISO 14001
High - tech Certification
